Workshop Vacuum Advice

Vic Perrin

Moderator
Executive Member
Joined
Feb 23, 2014
Posts
8,215
Location
Rugeley Staffs
First Name
Vic
I have recently brought the Dust Deputy Cyclone and looking for advice on the best shop vacuum to team it up with.

:thinks::thinks::thinks:


Phil Dart

Moderator
Executive Member
Joined
Nov 28, 2014
Posts
5,542
Location
Colebrooke, Devon
First Name
Phil
I've been very happy with my twin motor Camvac Vic. I can only speak from experience, but I did do quite a bit of research when I first bought it, and I'd buy the same again if it ever needed to be replaced. which because it's a Camvac, I'm assuming is a long way off yet.


GeordieB

Registered
Joined
Dec 26, 2014
Posts
2,979
Location
halifax
First Name
george
Mine is linked up to a camvac Vic but I am reluctant to recommend it as loads of people think it to noisy I can live with it and it could suck a golf ball down a hose pipe


Jim

Grand Master
Joined
Oct 19, 2011
Posts
15,616
Camvac's are noisy, or at least when i had one it was, but they are a super machine .. :thumbs:


Penpal

Grand Master
Joined
May 26, 2013
Posts
25,342
Location
Canberra AUSTRALIA
First Name
Peter
It is ideal if the vac is placed in another area regardless of the cleaner used but shop vacs over here are cheap as now an advantage is to have that in between chip collector. I learned that a whole of house vacuum was a waste of money died in the orifice and dammed dificult to empty.

Peter.:fingers::fingers:


Bill Mooney

Blind old git
Grand Master
Joined
Aug 16, 2014
Posts
11,234
Location
County Durham
First Name
Bill
A 21/2" hose on the exhausts of a camvac can reduce the noise quite a bit. The camvac isn't as noisey as the Axi neumatic I used to have.


Doug

Loquacious
Executive Member
Joined
Aug 25, 2013
Posts
6,723
Location
In the wood shop
First Name
Take a guess
Just had a look on the Rutlands site & saw the new dust deputy, as it has a 63mm tapered outlet it would be good to get a vacuum with at least a 2" inlet. Just because the hose on a vacuum isn't 2" doesn't mean the inlet on the vacuum won't be 2", my set up is here http://www.penturners.co.uk/off-topic-forum/6659-ta-billy.html I used 2" waste pipe between the Dust Deputy & the Vacuum

I'd also want the finest filtration I could get, 1 micron would be good but 0.5 would be better.
If you are going to be using it attached to power tools as I do then a vacuum with a power take off is a real boon.
All vacs are noisy, if you want a brand name then by all means go for one but any powerful, low filtering machine will do, you don't even need a large waste capacity because the deputy is collecting that, ideally you want the smallest vac that suits your needs.

Google is good as you can bring up lots of options & compare the noise levels & other specifications, I only know because I just googled "power take off vacuums" & there's a lot more brands than I'd imagined


silver

General dogsbody
Executive Member
Joined
Jun 29, 2013
Posts
6,303
Location
Somewhere in Staffordshire,
First Name
Eamonn.
Vic, have a look at Bill Pentz web site, Dust Collection Research - Home

It's the most comprehensive place for dust control for small workshop anywhere on the web.

Bill is over the pond, but the same rules apply no matter what country it's from.

The most important thing to remember is if you are putting in ducting to feed all machines or are you just providing it for one machine. The airflow for the ducting needs to be right to prevent dust build up and the risk of fire.

The Vacuume units are good but limit you to airflow, the cyclone efficiency will be effected with how much airflow you put through it as well.

The wood chip units are also good but they don't protect you from the PM 10 and below. That's why they say it's no good to collect dust. So you need to change the collection method to protect you by fitting a cartridge filter or install a 100mm cyclone unit.

Prob not much help to your original question, but it's all down to your finances and what system you want to install.
